Horizontal Single Axis Robot Servo Welding Positioner – High-Precision Automation Solution
Product Description
The Horizontal Single Axis Robot Servo Welding Positioner is engineered to enhance the precision and efficiency of your welding operations. With its servo-driven system, this positioner provides smooth, accurate rotation, ensuring optimal orientation for welding tasks. Designed to work seamlessly with industrial robots, the positioner supports heavy workpieces while offering the flexibility needed for various welding processes.
Ideal for industries like automotive, aerospace, and heavy machinery manufacturing, this positioner is built to withstand demanding environments while delivering high-quality welds. Whether you are working with small parts or large components, the horizontal single axis welding positioner provides consistent, reliable performance to improve your production cycle time and reduce manual labor.
| NO | Item | SWP-P-200 | SWP-P-500 | SWP-P-1000 | SWP-P-2000 |
| 1 | Rated load | 200kg(Spindle axis radius≤600mm) | 500kg(Spindle axis radius≤750mm) | 1000kg(Spindle axis radius 90omm) | 1000kg+1000k9 (Spindle axis radius 100omm) |
| 2 | Standard radius of gyration | R600mm | R750mm | R900mm | R2000mm |
| 3 | Maximum angle of gyration | ±360° | ±360° | ±360° | ±360° |
| 4 | Rated speed of gyration | 50°/S | 50°/S | 50°/S | 30°/S |
| 5 | Repeated positioning accuracy | ±0.08mm（At R=400mm） | ±0.08mm（At R=400mm） | ±0.08mm（At R=400mm） | ±0.15mm（At R=1000mm） |
| 6 | Horizontal rotary disc size | ≤1200mm(Standard configuration without gyration disc) | ≤1500mm(Standard configuration without gyration disc) | ≤1800mm(Standard configuration without gyration disc) | 2000mm*1000mm(L*w) |
| 7 | Positioner dimension (L×W×H) | 900mm×700mm×760mm | 900mm×700mm×750mm | 650mm*650mm*500mm | 3500mm*2200mm*1800mm(including theheight of the shading screen) |
| 8 | Tool tray size | Φ360mm | Φ390mm | Φ430mm | / |
| 9 | Height of the tool tray to the ground | 760mm | 780mm | 500mm | 500mm |
| 10 | Equipment net weight | About 270kg | About 300kg | About400kg | About 2500kg |
Product Features:
Single Axis Servo Drive: Provides smooth and accurate rotation for precise welding positions.
High Load Capacity: Capable of handling heavy workpieces, ideal for large or complex welding applications.
Adjustable Speed Control: Allows operators to customize speed for different welding tasks, improving flexibility.
Compact Design: Saves floor space and is ideal for environments with limited workspace.
Durable Construction: Built with high-quality materials for long-lasting performance in industrial environments.
Seamless Integration: Designed for easy integration with robotic arms, offering compatibility with top robotic brands like ABB, KUKA, and FANUC.
User-Friendly Interface: Intuitive controls for easy operation and setup, reducing training time.
Product Advantange
Precision and Consistency
The servo-driven mechanism ensures precise positioning of workpieces, guaranteeing uniform and high-quality welds across multiple cycles. This consistency minimizes the risk of defects and reduces rework, boosting overall productivity.
Enhanced Flexibility
With adjustable speed control, the positioner allows operators to fine-tune the rotation speed to meet the specific requirements of different welding applications, making it a versatile solution for various industries.
Heavy-Duty Capacity
Designed to handle heavy workpieces, the Horizontal Single Axis Robot Servo Welding Positioner supports the welding of large and complex parts, reducing the need for multiple manual adjustments or additional equipment.
Space-Saving Design
The compact design is perfect for environments where space is limited, making it ideal for high-demand production lines or facilities with limited floor space.
Seamless Robot Integration
This positioner is compatible with leading robotic arms and control systems, including ABB, KUKA, FANUC, and YASKAWA, ensuring smooth integration into existing robotic workflows and optimizing your automated welding process.
Long-Term Durability
Built with high-quality materials and precision engineering, the positioner is designed for long-lasting performance in harsh industrial environments. This durability translates into reduced maintenance costs and a longer service life.
Improved Safety
By automating the positioning of workpieces, the robot servo welding positioner reduces the need for operator intervention, minimizing the risk of accidents and enhancing workplace safety.
Transform your welding operations with the Horizontal Single Axis Robot Servo Welding Positioner. Enhance productivity, improve weld quality, and integrate seamlessly with your robotic systems. Contact us today for more information or to request a quote.
